92% Alumina Grinding Cylinder 32x32mm
Product Overview
What Is High Alumina Grinding Column
Alumina grinding column refers to the high-temperature calcined Alpha alumina powder as raw material, through batching, grinding, powder making, molding, drying, firing, and other processes
Alumina ceramic grinding columns make great ceramics, glasses, and enamels in chemical factories and other industries with ball mills, can-type mills, and vibration mills as their main machinery. Al2O3 Alumina grinding cylinder can also be used in these industries: metallic minerals, non-metallic minerals , silicon carbide, talcum, white pigments, cosmetics, cement, building materials.
High Alumina Ceramic Grinding Column applications
Apart from grinding usages, you can form rubber-backed ceramic wear liners with our alumina grinding cylinders. The main application for Alumina Ceramic Column is within the mining industry.
We suggest Al2O3 alumina grinding cylinders for stirred mills and ball mills preferably. Alumina grinding columns are widely used in different types of ceramics, enamels, glass, chemicals, etc. due to their excellent characteristics such as high strength, high hardness, high wear resistance, large specific volume, small volume, high-temperature resistance, and corrosion resistance.
high Alumina Grinding Column advantage
The alumina grinding column has a grinding efficiency and abrasion resistance far exceeding ordinary ball stone and natural pebbles. It is an excellent grinding medium for fine grinding equipment such as ball mills, pot mills, and vibration mills.
No abrasion, no corrosion, and no erosion. Alumina ceramic grinding columns resist almost everything. Acid, alkali, chips, extreme heat, and abrupt temperature changes, etc. Al2O3 Alumina grinding cylinder are also pollution-free, easy to clean, and 3-5 more durable than natural stone liners, and 23 times more durable than rubber liners. Installation and milling time are reduced at a minimum, while efficiency is augmented at a maximum.
• Wear-resistant low loss
• high-temperature resistance
• corrosion resistance
• High Mechanical Strength
High Al2O3 Alumina Ceramic Grinding cylinder specification
| Specification (mm) | Diameter (mm) | Height (mm) |
| Φ15*15 | 15 | 15 |
| Φ20*20 | 20 | 20 |
| Φ25*25 | 25 | 25 |
| Φ30*30 | 30 | 30 |
Alumina ceramic grinding Column Chemical Composition and Physical Properties
| Al2O3 | ≥ 92% | ≥ 95% |
| Fe2O3 | ≤ 0.01% | ≤ 0.01% |
| SiO2 | ≤ 5.28% | ≤ 2.6% |
| Na2O | ≤ 0.72% | ≤ 0.44% |
| Hardness | 9 Mohs | 9 Mohs |
| Water Absorption | ≤ 0.01% | ≤ 0.01% |
| Bulk Density | ≥ 3.6g/cm3 | ≥ 3.7g/cm3 |
| Compression Strength | ≥ 2000 Mpa | ≥ 2500 Mpa |
| Wear Loss | ≤ 0.001% | ≤ 0.0008% |
Note: As the grinding media, at a comparable weight with grinding balls, Al2O3 alumina ceramic grinding column have an approx.14% greater surface than alumina ceramic grinding ball.
Alumina Grinding Cylinder ,High Alumina Ceramic Grinding Media ,Ceramic Grinding Ball for Ball Mills ,Mining Wear-Resistant Ceramics ,Industrial Ceramic Grinding Cylinder
92% Alumina Grinding Media ,Ceramic Grinding Columns for Cement Plants ,Corrosion-Resistant Alumina Grinding Cylinder ,High-Temperature Abrasion-Proof Ceramics ,Low Wear-Loss Grinding Media ,Alumina Ceramic Grinding Media Supplier ,Precision Ceramic Grinding Tools
Zibo Qimingxing's 92% Alumina Grinding Cylinders: 23x More Durable Than Rubber Liners. Engineered for Mining, Cement, and Chemical Industries. High hardness, corrosion resistance, and wear longevity for efficient grinding operations.
STRICT INTERNATIONAL STANDARD (ISO) CERTIFICATION
Established a global quality management and environmental management system.
Passed the international standard certification established by the International Organization for Standardization (ISO). After a strict and systematic international review process, it is proved that the products and services provided to customers are strictly maintained.
ISO 9001 International Standard For Quality Management
Our Quality Management System is managed to consistently meet the needs of our customers with the highest global quality.
ISO14001 Environmental Management System Certification
Establish a world-class green management system to minimize harmful environmental factors and demonstrate that the energy, resource consumption and regeneration of our products are effectively managed.
ISO 45001 Occupational Health and Safety Management System Certification
ISO 45001 Occupational Health and Safety Management System evolved from OHSAS18001 Occupational Health and Safety Management System. This new standard is designed to help organizations around the world ensure the health and safety of their workers.
Applications
Mining & Metallurgy
Wear ceramic linings safeguard chutes, cyclones and pipelines during ore conveying and metallurgical material handling.
Cement & Building Materials
Ceramic wear liners for clinker transfer pipelines and powder processing equipment in cement and construction material plants.
Power & Energy Generation
Applied in coal mills, ash conveying pipelines and desulfurization systems of thermal power plants against abrasion.
Chemical & Coatings Industry
Abrasion & corrosion resistant ceramic linings for slurry transport and mixing equipment in pigment and chemical production.
Ceramics & Glass Manufacturing
High-performance ceramic wear parts for raw material conveying systems of ceramics and glass production lines.
New Energy & Lithium Battery
Low-contamination alumina ceramic liners for lithium powder conveying equipment in lithium battery raw material processing.
Product Advantages
High Hardness & Wear Resistance
Vickers hardness ≥ 1100 HV, offering significantly lower wear loss compared to traditional steel balls.
Cost-Effective Solution
Longer service life means fewer replacements and reduced downtime for your production lines.
Low Abrasion & Contamination
Minimal material wear ensures product purity and prevents contamination during grinding processes.
Precision Manufacturing
Advanced isostatic pressing technology ensures uniform density and consistent quality in every ball.
Custom Sizes Available
We produce balls from Ø 1mm to Ø 100mm, with custom sizes available to meet your specific requirements.
Global Shipping & Support
Fast worldwide shipping with professional technical support from our engineering team.
